Grand Manor / 6009

3D Tour

Floor Plan

Floor Plan Details

ManufacturedModularMH AdvantageFeatured
  • 3 Beds
  • 2 Baths
  • 1998 Sq. Ft.
  • 29’0″ x 68’0″

BUILT BY: KIT Custom Homebuilders

3 Bdr / 2 Bath / 1998 sqft. – The Grand Manor 6009 is Kit’s first of the new Grand Manor series. This Grand Manor Signature floor plan features an optional 9’ high, flat open-beam ceiling, ample windows that provide excellent natural lighting, interior barnwood accent colors, kitchen pot filler faucet, a glass panel walk-in tile shower with body massage faucet, entertainment center, beverage center, and much more!

Floor Plan Specifications

Bathroom Additional Specs: Full Width Mirror w/Wood Trim Around (matches cabinets) / Satin Nickel Towels Hooks & Tissue Holders / Temperature & Balance Control Valves on Shower Diverter
Bathroom Backsplash: 6” Ceramic Tile Backsplash
Bathroom Bathtubs: Cab Ply on Front of Master Deluxe Tubs
Bathroom Countertops: Laminate Counter Tops w/Rounded Crescent Edge
Bathroom Faucets: Double Handle Faucets
Bathroom Flooring: LX Vinyl Flooring
Bathroom Lighting: Ceiling Lights / Night Lights in Master Bathroom and Guest Bathroom
Bathroom Shower: Deluxe Master Bath with 6’ Fiberglass Deep Soaker Tub or 54” Roman tub and Separate 60” Fiberglass Shower (per plan) / 60” 1 Piece Fiberglass Tub/Shower in Guest Bath
Bathroom Sink: China Lavs
Bathroom Toilet Type: Elongated Toilet
Ac Ready: Conduit from panel box for air ready/heat pump ready
Additional Specs: OSB Under sheet rock on marriage line walls
Insulation (Ceiling): HUD: R-40 / Modular: R-50
Exterior Wall On Center: 16” O.C.
Exterior Wall Studs: 2x6 Exterior Walls
Floor Decking: HUD: Tongue and Groove OSB Floor Decking / Modular: 3⁄4”OSB Tongue & Groove Floor Decking
Insulation (Floors): HUD: R-33 / Modular: R-30
Floor Joists: HUD: 2x6 Floor Joists 16” O.C. on 26’8” & 40’ Wide Homes / 2x8 Floor Joists 16” O.C. on 29’6” Wide Homes / Modular: 2x10 Floor Joists 16” OC with 2x10 Rim Rails
Interior Wall On Center: 16” O.C.
Interior Wall Studs: 2x4 Interior Walls
Other: HUD: Foundation Ready / Modular: Removeable Chassis/Frame
Roof Load: 30# Roof load
Side Wall Height: 90” Sidewall Height
Insulation (Walls): R-21
Endwall Eaves: 16-inch Overhangs on both ends of homes
Front Rear Eaves: 14-inch on 26'8-inch and 40' homes(12-inch on 29'6-inch homes)
Additional Specs: Smart Panel Vertical wood siding with window trim on Ends and Back Door
Dormer: Craftsman Dormer and Dormer(s) (per plan)
Front Door: 36” Insulated Fiberglass Front Door (Almond, Clay, or White)
Hose Bibs: Frost Free Exterior Faucet (any location except end walls)
Rear Door: 36” 1⁄2 Lite Fiberglass Rear Door (Almond, Clay, or White)
Roof Pitch: HUD: 4/12 Roof Pitch on 26’8” Homes w/ 14” Eaves - 3.31/12 Roof Pitch on 29’6” Homes w/12” Eaves - 2.66/12 Roof Pitch on 40’ Homes with 14” Eaves / Modular: 3/12 Roof Pitch w/12” Eaves
Shingles: 30 Year Architectural Fiberglass Shingles
Siding: Fiber Cement Lap Panel Siding
Window Trim: Smart Panel Vertical Wood Siding with Window Trim on Ends and Back Door Side
Window Type: Low-E Vinyl Dual Glaze Windows (Almond, Clay, or White)
Carpet Grade: FHA Grade Carpet-Macrame / 6# Rebond Pad
Ceiling Type Or Grade: Textured Ceilings
Corner Wall Type: Rounded Corner
Door Carpet Type: LVT Plank Flooring at Entry Foyer
Door Fixtures: Satin Nickel Door Handles
Interior Doors: White 2-Panel Grand Arch Interior Doors w/2-1/4” Trim (Painted) With Lever Handles
Interior Lighting: LED Can Lights—(1) @ Entry Foyer and (2) @ Hall, & Walk-In Closets and Walk-In Pantries / Dining Room Chandelier / Ceiling Lights in Bedroom
Interior Corners: Radius corners
Interior Walls: Textured Walls and ceilings
Vaulted Ceilings: Vaulted ceilings
Window Type: Low E Vinyl Windows (Almond, Clay, or White)
Interior Paint: Choices of Interior Paints—Sherwin Williams washable eggshell finish
Kitchen Additional Specs: Frigidaire Appliances / Decorative Elliptical window over kitchen sink / USB Receptacle In Kitchen
Kitchen Backsplash: 6” Ceramic Tile Backsplash
Kitchen Cabinetry: Nayural Wood 52/31-inch Overhead cabinets w/adjustable shelves
Kitchen Countertops: Laminate countertops w/rounded crescent edge
Kitchen Dishwasher: Dishwasher (Energy Star® Qualified Appliance)
Kitchen Drawer Type: Drawer over Door Cabinet Construction / Deluxe Roller Bearing Drawer Guides / Bank of Drawers / 2 Sets of Pot and Pan Drawers w/Cab Doors (per plan) (9” Deep Pot & Pan Drawers in model 6009)
Kitchen Faucets: Satin Nickel Single Lever Faucet w/Pull Out Spout
Kitchen Flooring: LX Vinyl Flooring
Kitchen Lighting: (6) LED Can Lights / (2) Under Cabinet Lights
Kitchen Other: Laminate Window Sill in Kitchen
Kitchen Range Type: 30” Deluxe Electric Range
Kitchen Refrigerator: 21’ Frost Free Refrigerator w/ Icemaker
Kitchen Sink: 8” Deep Stainless Steel Sink / Decorative Elliptical Window Over Kitchen Sink
Additional Upgrades: Upgrades available (see retailer)
Additional Specs: Rocker Light Switches. USB Receptacle in Kitchen
Electrical Service: All Electric Home w/200 Amp Services
Electrical Wiring: Electrical Boxes nailed to studs
Furnace: Electric Furnace
Heat Duct Registers: Certified Heat Ducts with in-floor crossovers
Shut Off Valves Throughout: Master valve w/ Individual to sinks and stools
Thermostat: Programmable Thermostat
Washer Dryer Plumb Wire: Plumbed for Washer/Dryer
Water Heater: 50 Gallon Electric
Exterior Outlets: HUD: Exterior GFI Receptacle Near Rear Door / Modular: (2) Exterior GFI Receptacles

Tours & Videos

Photo Gallery

PLEASE NOTE: All sizes and dimensions are nominal or based on approximate builder measurements. S & H Manufactured Homes reserves the right to make changes due to any changes in material, color, specifications and features anytime without notice or obligation.
